Included in our Starter Kit, our PC GraphConverter software allows you to create your custom HMI and generate a reference file specific to your project.
This reference file contains a description of your project, lists all the HMI pages and includes the elements of your graphic chart (images, text zones, touch zones, logo, colors…).
Each of your graphic elements is defined by specific coordinates on the screen.
When programming the HMI, these coordinates will be used to fill in the parameters of the control commands provided.
You can find more information about this PC software here: HMI Editor Software GraphConverter.
